Scanstrut DS-H-MULTI-BLK Horizontal Black Cable Seal for Multiple Cables with Diameter up to 15mm
The Scanstrut DS-H-MULTI-BLK is a robust horizontal cable seal, engineered specifically for marine installers. Designed to route up to five cables (max. 15mm diameter), it delivers a clean, professional, and 100% watertight finish for marine electronics, solar panels, and lighting systems. Built from marine-grade, glass-filled nylon, this low-profile seal provides long-term durability against UV, saltwater, and harsh conditions.
Key Features:
- IP68 Rated – Ensures a 100% watertight seal in all marine environments
- Multiple Cable Entry – Accommodates up to 5 cables of varying sizes (up to 15mm)
- Marine-Grade Nylon – UV-stable, corrosion-resistant, and built for long-term durability
- Effortless Installation – Self-drill bung for custom cable layouts; no messy sealants required
- Compact Low-Profile Design – Just 35.8mm high, with a 114.8mm × 97.6mm footprint
- Captive Nuts – Secure assembly for reliable, repeat installations
- Professional Finish – Delivers a sleek, clutter-free appearance on decks and structures
What’s Included:
- 1 × Scanstrut DS-H-MULTI-BLK Horizontal Cable Seal
- 1 × Self-drill (undrilled) bung
- Fixing hardware
- Waterproof 3M gasket
- Installation instructions
Applications:
- Marine electronics installations
- Solar panel cable routing
- Deck and cabin lighting systems
- Custom boat wiring solutions
Click on the Details and Specification tabs for more information.
Specifications:
- Material: Marine-grade, high-impact, glass-filled nylon
- Height: 35.8mm
- Length: 97.6mm
- Width: 114.8mm
- Colour: Black
- Cable Capacity: Up to 5 cables (max. Ø15mm)
- Bungs: 1 × Self-drill (undrilled)
Please follow the installation instructions in the Documents tab.
