Scanstrut SC-USB-F3 Flip Pro Max Dual USB-C Fast Charging Socket – 12V/24V Marine & RV Waterproof Fast Charger
The Scanstrut Flip Pro Max (SC-USB-F3) delivers next-generation dual USB-C charging in a compact, waterproof design made for demanding marine and RV environments. Compatible with both 12V and 24V systems, it features 2 × 60W USB-C ports, providing the ultimate fast-charging solution for laptops, tablets, smartphones, and other high-powered devices onboard.
When not in use, the spring-loaded cap locks shut to protect against water and dust. When charging, it flips open and locks cables in securely—keeping them protected even in rough conditions. Built from premium marine-grade materials with a 316 stainless steel hinge, Flip Pro Max is IPX4 waterproof and washdown-ready, ensuring reliable performance in any environment.
Key Features:
- Dual USB-C Ports – 2 × USB-C outputs for charging two devices at once
- Ultra-Fast Charging – Up to 60W per port on 24V systems, perfect for laptops & tablets
- Compact & Retrofit-Friendly – Installs easily using a Ø32mm hole saw, bezel included
- IPX4 Waterproof – Sealed against spray and washdowns when cover is closed
- Marine-Grade Construction – UV-resistant body, anti-corrosion coating, and 316 stainless hinge
- Spring-Loaded Cover – Locks shut for protection, locks open to secure charging cables
- Universal Compatibility – Works with all USB-C devices, fast charging up to 2 at once
What’s Included:
- 1 × Scanstrut SC-USB-F3 Flip Pro Max USB-C Charger
- Mounting hardware
- Optional front-fit bezel
- Installation instructions
Applications:
- USB-C laptops and ultrabooks
- Tablets and smartphones
- Drones, action cameras, and GPS units
- Marine, campervan & RV 12V/24V systems
Click on the Details and Specification tabs for more information.
Specifications:
- Input Voltage: 10–32V DC (12V/24V systems)
- USB-C Output (12V System): 36W max (5VвЋ“3A, 9VвЋ“3A, 12VвЋ“3A)
- USB-C Output (24V System): 60W max (5VвЋ“3A, 9VвЋ“3A, 12VвЋ“3A, 15VвЋ“3A, 20VвЋ“3A)
- Max Input Current: 6A (10A fuse recommended)
- Standby Power Draw: 0.01W
- Certifications: CE, FCC, UKCA, C-Tick, ROHS, WEE
Please follow the installation instructions in the Documents tab.
